Triumph Tiger 955i Front Brake Rotor T2023330 From EBC MD676
The EBC MD676 front brake rotor is a 310mm floating disc for the 2004–2006 Triumph Tiger 955i with cast wheels, from VIN 198875. It is a direct replacement for Triumph front disc part number T2023330 and fits the stock wheel, two-piston calipers, and disc bolts without modification. One rotor fits either the left or right side of the front wheel.
EBC makes it in the UK from mill-rolled stainless steel, heat-treated and tempered for wear resistance, and diamond ground for a smooth, flat braking surface. That makes it a solid OE-type choice when your Tiger’s original disc is worn to its minimum thickness, warped and causing lever pulsation, or scored by worn-out pads.
EBC MD676 Specifications
- Position: Front, left or right
- Diameter: 310mm
- Type: Floating, with a gold center carrier and plain (round) outer profile
- Replaces: Triumph T2023330 (Disc, Front, 310)
- Sold: Each. The Tiger 955i has twin front discs, so order two to replace both sides.
- Matching EBC pads: FA196 series (FA196, FA196V, FA196HH)
- Made in: United Kingdom
Why Choose an EBC Floating Rotor
- Floating design: the outer braking ring can expand with heat independently of the center carrier. That reduces stress and the tendency to warp under hard or repeated braking.
- OE-quality stainless steel: mill-rolled stainless that EBC heat-treats and tempers for long wear life and resistance to cracking.
- Diamond ground finish: both faces are ground flat and parallel for smooth, vibration-free braking and quick pad bed-in.
- Direct fit: it matches the original Triumph disc’s size, offset, and bolt pattern, so no modification is needed.
Fitment
- Triumph Tiger 955i, 2004–2006, cast wheel models from VIN 198875 (to VIN 287503)
- Front wheel, left or right side
Check your VIN and wheels first. The 2001–2004 Tiger 955i with spoke wheels (VIN 124106 to 198874) uses a different 310mm front disc. EBC lists the solid MD649 for those bikes, or you can upgrade them with the EBC 310mm Front Brake Rotor Floating Disc Conversion PN MBI-MD601LS-FDC. The 2007-on Tiger 1050 uses a 320mm rotor, the Triumph EBC Front Brake Rotor PN MBI-MD679X.
Installation Tips
- Measure your old discs. Triumph stamps the minimum thickness on each disc, and a disc worn below it must be replaced.
- Fit new brake pads with new rotors. Old pads are worn to the shape of the old disc and will reduce braking until they bed in.
- Clean the wheel hub mounting face so the new rotor sits flat, and check that it runs true once fitted.
- Use new disc bolts with thread lock (Triumph T2023232), and torque them in a cross pattern to the figure in your Triumph service manual.
- Clean the braking surfaces with brake cleaner before fitting the wheel, then pump the lever to seat the pads before you ride.
- Bed in the new pads and rotors with a series of moderate stops before any hard braking.
- Follow the front brake procedures in chapter 10 of your Triumph Tiger 955i service manual.
Related Parts for Your Tiger 955i
- Triumph Tiger EBC 285mm Rear Brake Rotor PN MBI-MD677: the matching rear disc for the 2004–2006 Tiger 955i with cast wheels
- Triumph EBC Front Brake Pads PN MBI-FA196: EBC’s front pad for these calipers
- Brakes: more brake parts for your Triumph
Learn more about EBC rotor construction at EBC Brakes motorcycle rotors, or browse all EBC parts at Modern British Iron.
______________________________
Frequently Asked Questions
What Triumph models does the EBC MD676 front rotor fit?
It fits the 2004–2006 Triumph Tiger 955i with cast wheels, from VIN 198875. It goes on the front wheel, on either the left or right side.
What Triumph part number does EBC MD676 replace?
It replaces Triumph front disc T2023330 (Disc, Front, 310) used on the Tiger 955i from VIN 198875 to 287503.
Is the EBC MD676 sold as a pair?
No, it’s sold individually. The Tiger 955i has twin front discs, so order two to replace both sides at once.
Does the MD676 fit both the left and right side?
Yes. EBC lists the same MD676 rotor for both the left and right front positions on the Tiger 955i.
Is the EBC MD676 a floating rotor?
Yes. It’s a 310mm floating rotor with a gold center carrier. The outer braking ring can expand with heat independently of the carrier, which reduces stress and warping.
Will MD676 fit my spoke wheel Tiger 955i?
No. The 2001–2004 Tiger 955i with spoke wheels, up to VIN 198874, uses a different 310mm front disc. EBC lists MD649 for those bikes, or you can fit the MD601LS floating disc conversion.
Does the MD676 fit the Tiger 1050?
No. The 2007-on Tiger 1050 uses 320mm front rotors with radial calipers. EBC’s rotor for that bike is the MD679X.
Which brake pads should I use with the EBC MD676?
EBC lists its FA196 series front pads for the cast wheel Tiger 955i: FA196 organic, FA196V semi-sintered, and FA196HH sintered. Fit new pads whenever you replace the rotors.
How do I know when my Tiger 955i front rotors need replacing?
Replace them when they’re worn below the minimum thickness stamped on the disc, warped enough to cause lever pulsation, cracked, or deeply scored.
Do I need new disc bolts when fitting the EBC MD676?
New bolts are recommended. Use new Triumph disc bolts (T2023232) or equivalent with thread lock, and torque them to the figure in your service manual.
Is the EBC MD676 a direct fit?
Yes. It matches the original Triumph disc’s diameter, offset, and bolt pattern and works with the stock calipers, so no modification is needed.
Where are EBC brake rotors made?
EBC Brakes makes its motorcycle rotors in the United Kingdom from mill-rolled stainless steel that is heat-treated, tempered, and diamond ground.
The product images shown are for illustrative purposes only and may not be an exact representation of the product received. Manufacturers occasionally make minor cosmetic changes to items, such as color, finish, label, or design. These changes do not impact the item’s function or compatibility. Please contact us if you have specific concerns regarding appearance.
